Side Tilt Carriages

There are actually 4 sizings of hook type tine carriages rated by the tine carriage hoisting capacity. Hook type fork carriages have been the same.

Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing used for Class I is thirteen inches. Class II carriages are rated for loads up to 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for cargo up to 10,000 lbs. The carriage bar spacing for this particular class is 20 inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing used for this capacity is twenty five inches.

Pin mounted forks vary by the amount of offset between the fork and the blade eye. Various manufacturers would differ the carriages for pin type forks. Carriage capacity would be determined by the carriage pin size and by the fork size.

Click to Download the pdf
